BX Multipole Vacuum Ejector
Feature
- Mini size, compact structure
- Multi-pole design, low energy consumption
- Can provide larger vacuum flow
Detailed Specifications
| MODEL | Air supply pressure bar |
Vacuum degree -kpa |
Vacuum flow L/min |
Air consumption L/min |
Height L (mm) |
Recommended pipe diameter for air supply holes | Recommended Pipe Diameter Vacuum Orifice | Weight g |
|---|---|---|---|---|---|---|---|---|
| BX10-C | 4-6 | 92 | 62 | 43-48 | 23 | Ø6 | Ø8 | 215 |
| BX20-C | 4-6 | 92 | 124 | 86-96 | 30 | Ø6 | Ø10 | 215 |
| BX30-C | 4-6 | 92 | 185 | 129-144 | 37 | Ø8 | Ø12 | 260 |
